Sag test according to DIN 55 677

SKU MTVAR-DIN
€910.00
Excl. Shipping
Product Details
Weight: 0.35 kg

Sag test VAR in accordance with DIN 55 677

A total of 24 columns are attached to the four drawing edges of the rake. The columns are 10 mm wide and have a distance of 2 mm.
For simple and practical testing, for determining the flow and flow behavior of paints, varnishes and other paints
Technical data:
  • 24 columns
  • 10 mm wide, distance of 2 mm
  • Gap heights: 75 to 1300 μm
  • Thickness of the drawing edge: 3 mm (does not correspond to the standard)
  • Weight 120 g
  • Dimensions (L x W x H) 110 x 35 x 15 mm
  • Warranty 1 year manufacturer's warranty on material and workmanship defects

Scope of delivery:
  • Sag test VAR in accordance with DIN 55 677


All prices are shown without VAT and shipping cost. Sale only to entrepreneurs, businesses, freelancers and public institutions. No sale to consumers within the definition of § 13 BGB.

In stock
